Price of lathe CA6166 CA6266 with sliding bed
| parameters | CA6161/CA6261/CA6161B/CA6261B/CA6161C/CA6261C |
|---|---|
| Maximum drilling diameter | 610mm |
| Maximum swing diameter over carriage | 370mm |
| Maximum swing (optional) | 830mm |
| Effective clearance length | 210mm |
| Maximum workpiece length | 750/1000/1500/2000/2200/3000/4000mm |
| Bed width | 400mm |
| Cutting tool section | 25 X 25mm |
| Spindle speed | 16-1400rpm(24steps) |
| Bore through spindle | 52mm ,[80mm （Type B）], [ 105mm（Type C）] |
| Spindle nose | ISO（GB）C6/D8(Type B、Type C） |
| Spindle connection | No.6(MT6) [Φ90 1:20 ( Type B）] [Φ113 1:20（Type C）] |
| Number of feeds | (64 kinds)(for each) |
| Metric thread range | (1-192mm) (44 kinds) |
| Inch thread range | (1-24tpi) (21kinds) |
| Module thread range | 0.25-48 (module 39 kinds) |
| Thread diameter pitch range | 1-96DP (37 kinds) |
| Maximum tailstock spindle stroke | 150mm |
| Spindle shank diameter | Φ75mm |
| Spindle shank bore taper | MT 5 |
| Main motor | 7.5KW(10HP) |
| Overall dimensions for 750 mm | 2440*1140*1750mm |
| Overall dimensions for 1000 mm | 2650*1140*1750mm |
| Overall dimensions for 1500 mm | 3150*1140*1750mm |
| Overall dimensions for 2000 mm | 3650*1140*1750mm |
| Overall dimensions for 3000mm | 4800 *1140*1750mm |
| Overall dimensions for 4000mm | 5680 *1140*1750mm |
| Length | G.W. N.W. |
| Overall dimensions for 750mm | 2300KG 2180KG |
| Overall dimensions for 1000mm | 2380KG 2250KG |
| Overall dimensions for 1500mm | 2577KG 2437KG |
| Overall dimensions for 2000mm | 2940KG 2787KG |
| Overall dimensions for 3000mm | 3750KG 3600KG |
| Overall dimensions for 4000mm | 4350KG 4200KG |
Description:
The saddle lathe (CA6266) has all the design features and characteristics of the basic lathe (CA6166), and also has a saddle attached to the body, which expands the machining range of the machine. The saddle is easy to dismantle, and the repeat positioning accuracy is high. After removing the saddle, it can process special parts of irregular shape and large diameter workpieces. It is widely used in various fields of mechanical processing for both single and batch production, and is also a suitable accessory for scientific research institutions.
The lathe is wider than ordinary machines; its structural rigidity and transmission rigidity are higher, which ensures stable accuracy and the ability to perform powerful cutting.
Simple operation with one lever.
The main lubrication system circulates outside the body, improving the machining accuracy.
Standard accessories:
Three-jaw chuck head
Center support tool guard
Support stop with lead screw guard
Foot tray Coolant system
Face plate Lubrication system
Rear protective cover Work lamp
Tool box
Optional accessories:
Four-jaw chuck head
Digital coordinate display
Quick-release tool holder
Support and support device
Support stop with chuck guard
